24V 150Ah Rechargeable Li Ion Battery Pack 24V LiFePO4 Battery For uninterruptible Power Supplies
Are you looking for the the best LiFePO4 battery?
Bely has you covered offering the latest in high performance lithium batteries for your needs!
lithium battery up to 5x the lifespan of standard lead-acid battery. This series is temperature resistant and lightweight, and offers a higher charge/discharge cycles, about 2,000 cycles at 80% DOD (depth of discharge). LiFePO4 cathode is intrinsically safer than the LiCo02 or the manganese cathode. Our wide variety of standard and high performance batteries ensure we have what you need, when you need it.
Superior Character
1. Super Long Service Life
2. High Safety Ensured by Smart BMS
3. Fast Charge and High Rate Discharge Power
4. Low Total Cost of Ownership (TCO)
5. High Energy Density by Adopting LFP Cells 6. High Cycle Round Trip Efficiency (RTE)
7. Wide Working Temperature Range 8. Maintenance Free
Product Description
BLY-A02-24V150AH LiFePO4 Battery Ideal Replacement of Traditional Lead Acid Battery
ES-LFP Series Lithium-ion Battery is an ideal replacement for traditional lead acid battery utilizing advanced LiFePO4 technology and integrated BMS with the benefits of long cycle life, light in weight, safety and excellent high and low temperature performance. ES-LFP Series Lithiumion.Battery is widely used in energy storage, UPS, golf cart and other lead acid battery replacement.
Information
BATTERY MANAGEMENT SYSTEM
The battery Management system (BMS) installed in every battery ensures that the battery in the event of under voltage or overload switches off and automatically again turns on as soon as the problem is resolved.
Protection of the cell against under voltage by switching off the load in good time.
- Protection of the cell against over voltage by reducing the charging current or switching off the charging process.
- Shutting down the system in the event of excess temperature.
- Charging of the battery is stopped in case of under temperature.
EASY REPLACEMENT THE EXISTING BATTERY
The dimensions of the housing are identical with the most common AGM, lead acid or GEL batteries. With optionally available round poles can also use existing pole, terminals can be reused. An exchange the battery holder or a change the loading structure is not necessary.
BATTERY CHARGING
Use the suitable lithium battery charger. Waiting until the battery is fully charged.
PERFORMANCE / EFFICIENCY
A BeLY LiFePo4 battery can do more than 96% of the energy made available directly to save. A 100% utilization of the existing capacity takes place with the same output voltage.
Specification of Lifepo4 Battery 24V 150AH
| Specification | Parameter | Remarks |
| Nominal | Voltage | 25.6V |
| Capacity | 150Ah/3840Wh |
| Physical | Dimension | 522mm x 267mm x 220mm |
| Weight | 40KGS |
| Electrical | Discharge Voltage | 25.6V |
| Charge Voltage | 25.6~29.4V |
| Charging Current | 100A |
| Discharging Current | 150A |
| Others | Charging Temperature Range | 0~55℃ |
| Discharging Temperature Range | -20~60℃ |
| Storage Temperature Range | -20~60℃ |
| Cycle Life | ≥5000Cycles |
| Internal Impedance | ≤50mΩ |
| Battery Cells Type | Prismatic |
| Material | Black or customized |
| Life time @+25℃ | 10 years |
OEM/ODM Service:
If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it. Contact with our sales team to get more informations about us and products.
APPLICATION AREAS
Our lithium iron phosphate batteries can be used in the following areas: Home energy storage system, UPS backup, lighting, digital/CCTV cameras, portable TV, e-Robot, electric vehicles, DIY loud speaker, air pump, fish finder, golf car, trolling motor, motorhome / RV & camper, Houseboat, Travel Trailer, Dump Trailer and more.
Why choose us:
1. We offer one-stop power solutions, which saves design time and cost for customer:
-- Pack design / External Case design / BMS design
2. Strict quality control system which enhances customers' competitiveness:
-- 100% PCM test by IQC
-- 100% Capacity test by OQC
3. Delivery on time & excellent service:
-- Fast Delivery in 10 days if stock
-- 8h response & 48h solution
4. Experienced R&D team, be customer's professional power solution consultant:
-- Comprehensive Battery Test Center (Safety and Reliable test)
-- Powerful ODM Ability to Afford Customized Design Requirement
